PN6775,PN6780,PN6795,PN8680,PN8386,PN6367
集成超低待機功耗原邊控制器及高雪崩能力智能功率MOSFET，用于高性能、外圍元器件精簡的充電器、適配器和內(nèi)置電源。PN6775為原邊反饋工作模式，可省略光耦和TL431。內(nèi)置高壓啟動電路，可實現(xiàn)芯片空載損耗（230VAC）小...
產(chǎn)品描述：
AC-DC(PSR)
| Product | Character | SW Voltage | Standby Power | RDS(on) | VDD Operation Voltage | Output Power | CC/CV precision | Package | Note |
|---|---|---|---|---|---|---|---|---|---|
| PN6775 | CC/CV PSR Converter | 650V | <50mW | 13Ω | 10~30V | 6W | ±5% | SOP8 | Home |
| PN6775H | CC/CV PSR Converter | 800V | <50mW | 14Ω | 10~30V | 6W | ±5% | SOP8/DIP8 | Home |
| PN6780 | CC/CV PSR Converter | 650V | <50mW | 3.5Ω | 10~30V | 12W/15W | ±5% | SOP8/DIP8 | Home |
| PN6780H | CC/CV PSR Converter | 800V | <50mW | 3.5Ω | 10~30V | 12W/15W | ±5% | SOP8/DIP8 | Home |
| PN6795B | CC/CV PSR Converter | 650V | <50mW | 2.5Ω | 10~30V | 22W | ±5% | DIP8 | Home |
| PN6795C | CC/CV PSR Converter | 650V | <50mW | 2.1Ω | 10~30V | 24W | ±5% | DIP8 | Home |
| PN6795D | CC/CV PSR Converter | 650V | <50mW | 1.6Ω | 10~30V | 28W | ±5% | DIP8 | Home |
| PN8680M | CC/CV PSR Converter | 650V | <50mW | 6Ω | 10~30V | 12W | ±5% | SOP8 | Charger/Adapter |
| PN8680P | CC/CV PSR Converter | 650V | <50mW | 2.5Ω | 10~30V | 15W | ±5% | SOP8 | Charger/Adapter |
| PN8680T | CC/CV PSR Converter | 650V | <50mW | 1.6Ω | 10~30V | 18W | ±5% | SOP8 | Charger/Adapter |
| PN8386 | CC/CV PSR Converter | 650V | <50mW | 4Ω | 10~30V | 18W | ±5% | SOP8 | Charger/Adapter |
| PN8390 | CC/CV PSR Converter | 650V | <50mW | 3Ω | 10~30V | 18W/24W | ±5% | DIP8/SOP8 | Charger/Adapter |
| PN6367 | CC/CV PSR Converter | 680V | <5mW | 8Ω | 10~30V | 20W | ±5% | SOP7 | Automatic Reclosing Protector |
| PN6367P | CC/CV PSR Converter | 680V | <5mW | 4Ω | 10~30V | 60W | ±5% | SSOP10 | Automatic Reclosing Protector |
| PN6370M | CC/CV PSR Converter | 690V | <50mW | 18Ω | 10~30V | 5W | ±5% | SOP7 | Charger/Adapter |
| PN6370H | CC/CV PSR Converter | 690V | <50mW | 4Ω | 10~30V | 18W | ±5% | DIP7 | Charger/Adapter |
| PN6370P | CC/CV PSR Converter | 690V | <50mW | 2.5Ω | 10~30V | 12/15W | ±5% | SOP7/DIP7 | Charger/Adapter |
| PN8570M | CC/CV PSR Converter | 800V（VCBO） | <75mW | - | 10~30V | 5W | ±5% | SOP7 | BO/AC Line OVP |
| PN8575P | CC/CV PSR Converter | 800V（VCBO） | <75mW | - | 5~20V | 12W | ±5% | SOP8 | BO |
| PN8577 | CC/CV PSR Converter | 800V（VCBO） | <75mW | - | 4.5~21V | 18W | ±5% | SOP8 | Charger/Adapter |
| PN8580 | CC/CV PSR Converter | 650V | <75mW | 5Ω | 10~30V | 12W | ±5% | SOP8 | Charger/Adapter |
