CYT1000AEG single segment LED linear constant current control chip
CYT1000AEG is a linear constant current IC with adjustable outputcurrent, high constant-current accuracy, simple application scheme, Cost andResistance capacitance step-down are comparable, with over-...
Model:
Product Description:
CYT1000AEG is a linear constant current IC with adjustable outputcurrent, high constant-current accuracy, simple application scheme, Cost andResistance capacitance step-down are comparable, with over-temperatureprotection function, safer and more reliable.
5mA to 60mA adjustable output current,
accuracy of constant current can reach ±5%
With over-temperature protection function
No EMI problem
Chip and LED share aluminum substrate
Simple circuit, cost-effective
Package: ESOP8
| 產品型號 | 最大電流 | 恒流精度 | 通道 | OTP溫度 | MOS管 | MOS電壓 | 封裝 |
| CYT1000AE | 60mA | ±5% | 1 | 120℃ | 內置 | 500V | ESOP-8 |
| CYT1000AEG | 60mA | ±5% | 1 | 140℃ | 內置 | 500V | ESOP-8 |
| CYT1000A | 120mA | ±5% | 2 | 120℃ | 內置 | 500V | ESOP-8 |
| CYT1000AG | 120mA | ±5% | 2 | 140℃ | 內置 | 500V | ESOP-8 |
| CYT1000B | 60mA | ±5% | 1 | 120℃ | 內置 | 500V | TO252-2 |
| CYT1000BG | 60mA | ±5% | 1 | 140℃ | 內置 | 500V | TO252-2 |
| CYT1000DE | 60mA | ±5% | 1 | 140℃ | 內置 | 500V | SOT89-3 |
| CYT1000AH | 80mA | ±3% | 1 | 150℃ | 內置 | 700V | ESOP-8 |
| CYT1000AGH | 120mA | ±5% | 2 | 140℃ | 內置 | 700V | ESOP-8 |
| CYT1000BH | 80mA | ±4% | 1 | 150℃ | 內置 | 700V | TO252-2 |
| CYT1000DH | 80mA | ±4% | 1 | 150℃ | 內置 | 700V | SOT89-3 |
| CYT1010BS | 120mA | ±5% | 1 | 140℃ | 內置 | 500V | TO252-2 |
| CYT16G | 60mA | ±5% | 1 | 140℃ | 內置 | 500V | SOT23-3 |
| CYT1002AEG | 100mA | ±5% | 1 | 140℃ | 內置 | 700V | ESOP-8 |
| CYT1012BS | 120mA | ±5% | 1 | 150℃ | 內置 | 700V | TO252-2 |
| CYT1012BM | 185mA | ±5% | 1 | 150℃ | 內置 | 700V | TO252-2 |
| CYT1005AEG | 45mA | ±5% | 1 | 130℃ | 內置 | 500V | ESOP-8 |
| CYT1005AG | 90mA | ±5% | 2 | 130℃ | 內置 | 500V | ESSOP-10 |
| CYT1004AEG | 45mA | ±5% | 1 | 160℃ | 內置 | 500V | ESOP-8 |
| CYT3000BM | 100mA | ±5% | 3 | 145℃ | 內置 | 700V | ESOP-8 |
| CYT3000E | 100mA | ±5% | 4 | 145℃ | 內置 | 700V | ESOP-8 |
| CYT3012B | 100mA | ±5% | 5 | 140℃ | 內置 | 700V | ESOP-16 |
| CYT8011TG | 60mA | ±3% | 2 | 140℃ | 內置 | 500V | ESOP-8 |
| CYT8000C | 60mA | ±3% | 2 | 150℃ | 內置 | 500V | ESOP-8 |
| CYT8000D | 100mA | ±3% | 2 | 150℃ | 內置 | 500V | ESOP-8 |
| CYT101D | 30mA | ±3% | 1 | 150℃ | 內置 | 90V | SOT23-3 |
