ICL1104 Single Channel HV Constant Current LED Driver
ICL1104 is a single channel high voltage linear constant current LED driver, which integrates 8DOV high voltage MOS. The output current can be set through an external resistor between 5mA and 80mA. IC...
Model:
Product Description:
ICL1104 is a single channel high voltage linear constant current LED driver, which integrates 8DOV high voltage MOS. The output current can be set through an external resistor between 5mA and 80mA. ICL1104 built-in linear type thermal protection function to effectively prevent damage to the system caused by high temperature. ICL1104 system has simple peripherals, flexible application, high reliability, small volume, low system BOM cost, adjustable packaging technology can be applied to all kinds of LED lamps.
850V/ 80mA HV NMOS integrated.
Constant current control technology.
System efficiency up to 93%.
Linear type thermal protection function.
NO EMI issue.
Various thermal protection trip temperature
available.
