CYT1000A 雙通道線性恒流LED控制芯片
產(chǎn)品描述：
CYT1000A is a linear constant current IC with adjustable outputcurrent, high constant-current accuracy, simple applicationscheme. Cost and Resistance capacitance step-down arecomparable, with over-temperature protection function, safer andmore reliable.
5mA to 60mA adjustable output current, accuracy of constant
current can reach ±5%
With over-temperature protection function
No EMC problem
Chip and LED share aluminum substrate
Simple circuit, cost-effective
Package: ESOP8
Applications
LED bulb
LED fluorescent lamp
LED down lamp
LED ceiling light
Other LED lightings
